3.4.9 Electrical Data
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
OPT: Rated Motor Output (kW)
FLA: Full Load Ampacity (A)
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
TIWM006B21S
208/230 1 60 253 188
0.3 15 0.038 0.2
TIWM008B21S 0.3 15 0.038 0.2
TIWM012B21S 0.5 15 0.038 0.4
TIWM015B21S 0.4 15 0.038 0.3
TIWM018B21S 0.6 15 0.038 0.5
TIWM024B21S 0.7 15 0.038 0.6
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
