3.1.3.8 Electrical Data
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
OPT: Rated Motor Output (kW)
FLA: Full Load Ampacity (A)
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
(H,Y)IDH018B21S
208/230 1 60 253 188
1.45 5 0.13 1.13
(H,Y)IDH024B21S 2.10 5 0.15 1.56
(H,Y)IDH030B21S 2.10 5 0.15 1.52
(H,Y)IDH036B21S 2.88 5 0.25 2.13
(H,Y)IDH048B21S 3.12 5 0.28 2.31
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
