Johnson Controls HIDH018B21S - Air Outlet Shutter Plate: PIS-56 LS

OPTIONAL PARTS
TC-15001-rev.3
5-23
5.5.5 Air Outlet Shutter Plate: PIS-56LS
NOTES:
1. When the indoor unit is installed with a clipped ceiling, the air outlet shutter plate must be used.
2. Refer to the “Installation Manual for Air Outlet Shutter Plate” for more details.
6SHFL¿FDWLRQV
Model
Item
PI-160LS1
Applicable Indoor Unit Model
((H,Y)IC1**B21S)
MBH 006 to 015
Quantity per unit 1
Material
Shutter Plate Polyethylenes
Sheet Non-woven Fabric (Flame Resistance: UL94V-0)
Unit: inch [mm]
