CONTROL SYSTEM
TC-15001-rev.3
6-137
1. Insert the memory card into the
Controller. Refer to “6.9.9 Use of
Memory Card”.
2. Select “Memory Card” from the
Service Menu screen.
NOTE:
This function is not available when
the memory card has not been
inserted.
3. Select “Write to the memory card”
from the Memory Card Menu.
Ɣ If there is no /CS-EZ folder in
WKHPHPRU\FDUGDFRQ¿UPDWLRQ
screen will be displayed.
Select “Yes” to create a /CS-EZ folder.
4. Select the folder to save.
Ɣ ,QWKHIROGHU¿HOGDIROGHUXQGHUWKH
/CS-EZ folder of the memory card
that will be displayed.
5. 7RXFK³1HZ¿OH´
6. Touch “Write” to start saving the data.
Refer to 6.9.9 “Use of Memory Card”.
7. Touch “Completed” from the
FRQ¿UPDWLRQVFUHHQWRUHWXUQWRWKH
“Memory Card Menu” screen.
6.9.11.9 Memory Card
6.9.11.9.1 Save Setting in New File
6
4
5
7
3
2
Continue on to Next Page
