System Architecture Proprietary Receiving Unit Overview

72 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014

Figure 7.6 Proprietary Receiving Unit System - Example 2

Supervising Station Transmission and Communications Path Protected Premises Unit

Workstation/

PC Gateway/

Receiver Gateway

Digital Alarm

Communicator Receiver

NFN Network

RS-232

PRU
