Physical and connection data
5.2.2 Electrical connections
The screw compressor unit can be controlled by a Unisab III regulation and control system, which
is mounted on the unit and connected to a number of temperature and pressure sensors on the
unit.
Fig. 58: Positions of valves and components
154160161
162
157
159
152
151
158
EC
