Page #169 background imageLoading...
Page #169 background image
FORM 160.54-O1
169
JOHNSON CONTROLS
The Control Center provides the required formatting con-
trol codes for the printers above when the printer is se-
lected on the PRINTER Screen in the instructions below.
These codes are transmitted through the serial interface
to the printer to provide a proper print format. Different
printers require different formatting control codes. Other
printers might provide proper operation when connected
to the Control Center. However, the print format may not
be correct or as desired. Proceed with caution and use the
following guidelines if an unlisted printer is selected:
1. All must be capable of RS-232 Serial communic-
ations.
2. Primary differences between printers involve the for-
matting control codes required by the printer. These
codes are sent from the Control Center to the printer.
For example, Weigh -Tronix printers require a control
code to select 40 column width. This same code is
interpreted by the Okidata printer as an instruction
to print wide characters. In some instances, a printer
will ignore a code it cannot interpret.
3. The Control Center requires a busy signal from the
printer when the printer receive buffer is full. This
causes the Control Center to momentarily terminate
data transmission until the printer can accept more
data. The busy signal polarity must be asserted low
when busy.
PRINTER CONNECTIONS
Connect the printers to the Control Center Microboard as
follows. Only one printer can be connected at a time.
OKIDATA 182, 182 turbo, 184 turbo
Microboard Printer Function
J2-4 pin 3 Tx (data to printer)
J2-2 pin 11 DSR (busy signal from printer)
J2-9 pin 7 Gnd
Cabinet shield
WEIGH-TRONIX
Microboard Printer Function
J2-4 pin 2 Tx (data to printer)
J2-2 pin 5 DSR (busy signal from printer)
J2-9 pin 7 Gnd
Cabinet shield
SEIKO
Microboard Printer Function
J2-4 pin 3 Tx (data to printer)
J2-2 pin 8 DSR (busy signal from printer)
J2-9 pin 5 Gnd
Cabinet shield
Hardware required:
Cable – #18 AWG stranded 50 ft. maximum length.
Connectors
- Microboard: None. Strip 1/4" insulation from
wire and insert into screw terminal block.
- Printers: Okidata - 25 pin plug DB-25P or equiv-
alent; Shell DB-C2-J9 or equivalent. Weigh-Tronix
- Same as Okidata. Cable assembly available from
Weigh-Tronix. Seiko - 9-Pin D-type Subminiature
(DB-9 pin male).
PRINTER SETUP
The selected printer must be congured as follows.
Refer to manual provided by Printer manufacturer with
respective Printer.
OKIDATA 182, 182 turbo, 184 turbo Printer
CONTROL BOARD Switch settings:
SW1 - on Unslashed 0
2 - off Unslashed 0
3 - off Unslashed 0
4 - off Form Length 11 in.
5 - on Form Length 11 in.
6 - off Auto Line Feed off
7 - on 8 bit data
8 - off Enable front panel
If equipped with a SUPER SPEED serial Board:
SW1-1 - on Odd or even parity
1-2 - on No parity
1-3 - on 8 bit data
1-4 - on Protocol ready/busy
1-5 - on Test select
1-6 - on Print mode
1-7 - off SDD(-) pin 11
1-8 - on SDD(-) pin 11
2-1 - on 1200 Baud*
2-2 - on 1200 Baud*
2-3 - off 1200 Baud*
2-4 - off DSR active
2-5 - on Buffer threshold 32 bytes
2-6 - on Busy signal 200ms
2-7 - on DTR space after power on
2-8 - Not Used
3
