JOHNSON CONTROLS
16
FORM 160.54-O1
ANALOG INPUT RANGES
The following table indicates the valid display range for each of the analog input values. In the event that the input
sensor is reading a value outside of these ranges, the < or > symbols will be displayed beside the minimum or maxi-
mum value, respectively.
*Saturation temperatures are calculated values. They will display XXX if the pressure used for the calculation is out of range.
**Not applicable to chillers equipped with Flash Memory Card version C.MLM.01.03 and later.
***7.5 PSIG Flash Memory Card Version C.MLM.01.04 and later.
ANALOG INPUT
ENGLISH RANGE METRIC RANGE
LOW HIGH UNITS LOW HIGH UNITS
Leaving Chilled Liquid Temperature 0.0 82.0 °F -17.7 27.7 °C
Return Chilled Liquid Temperature 0.0 94.1 °F -17.7 34.5 °C
Leaving Condenser Liquid Temperature 8.0 133.5 °F -13.3 56.3 °C
Return Condenser Liquid Temperature 8.0 133.5 °F -13.3 56.3 °C
Evaporator Refrigerant Temperature (Optional) 0.0 126.1 °F -17.7 52.3 °C
Discharge Temperature 31.8 226.3 °F -0.1 107.9 °C
Oil Temperature 31.8 226.3 °F -0.1 107.9 °C
Condenser Pressure (R22 and R134a) ***0.0 315.0 PSIG 0.0 2172.4 KPAG
Condenser Temperature (R22)* -122.1 130.9 °F -85.6 54.9 °C
Condenser Temperature (R134a)* -98.7 160.1 °F -72.6 71.7 °C
Evaporator Pressure (R22 – water) 49.4 128.8 PSIG 340.6 888.2 KPAG
Evaporator Pressure (R22 – brine) 25.0 100.0 PSIG 172.4 689.6 KPAG
Evaporator Pressure (R134a) 5.5 77.4 PSIG 37.9 533.7 KPAG
Evaporator Temperature (R22 – water)* 13.0 67.0 °F -10.5 19.4 °C
Evaporator Temperature (R22 – brine)* -18.0 51.4 °F -27.7 10.7 °C
Evaporator Temperature (R134a)* -44.9 64.7 °F -42.7 18.1 °C
Oil Sump Pressure (R22) 23.2 271.8 PSIG 160.0 1874.4 KPAG
Oil Sump Pressure (R134a) 0.0 315.0 PSIG 0.0 2172.4 KPAG
Oil Pump Pressure (R22 and R134a) 0.0 315.0 PSIG 0.0 2172.4 KPAG
High Speed Thrust Bearing Proximity Position
(Style E and earlier chillers with G, H, or J 8.0 99.0 Mils -7.1 148.8 °C
compressors and Style F and later chillers with
J or H3 compressors)
High Speed Thrust Bearing
19.1 300.0 °F -7.1 148.8 °C
Drain Temperature
**
Refrigerant Level 0.0 100.0 % 0.0 100.0 %
Drop Leg Refrigerant Temperature 0.0 121.7 °F -17.7 49.8 °C
LANGUAGES
The Screens can be displayed in various languages.
Language selection is done on the USER Screen. The
desired language is selected from those available. Not all
languages are available. English is the default language.
If a language other than English is being displayed, an
English-only speaking person should navigate to the
USER Screen using the preceding Navigation chart
and select English per the USER Screen instructions
in this book.
OptiView Control Center
