V Range 501 l 651 l 801 Maintenance Manual
MA1:8
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Water System Hose reel 60 None
1
Water System Low pressure spray bar (Located under
front spray bar)
30 None
1
Water System Low pressure nozzle (Includes cleaning
nozzle (All nozzles)
10 None
1
Water System Low pressure gutter spray (Includes
cleaning nozzles)
20 None
1
Water System High pressure spray bar (Located
under front bumper)
30 None
1
Water System High pressure spray bar mounting
(Spray bar removed)
15 None
1
Water System Suction box low pressure nozzles 15 None
1
Water System Suction box high pressure spray bar 10 None
1
Water System Nozzles (Includes cleaning) 15 None
1
Water System Wander hose low pressure nozzle
(Includes cleaning)
10 None
1
Water System Wander hose low pressure water tap 15 None
1
Water System Supa-wash pump (Includes check and
top up hydraulic oil level)
60 None
1
Water System Water solenoids (Includes cleaning seal
and valve - each)
15 None
1
Water System High pressure water tap (Front high
pressure spray bar and suction box
high pressure spray bar - each)
20 None
1
Water System Water ller neck lter (hydrant ller) 10 None
1
Water System Water tank suction lter 15 None
1
Water System Water tank breather 25 None
1
Water System Water lter assembly (R/H rear) 30 None
1
Electrical
System
Centre Console (Including software
update and test)
20 TB1570
1
Electrical
System
JVM Screen (Including software update
and test)
30 TB1555 & TB1570
1
Electrical
System
Keypad Node (Including software
update and test)
20 None
1
Electrical
System
Pendant (Including software update
and test)
15 None
1
Used oils and filters should be disposed of in accordance with the local
waste disposal regulations.
These procedures should be carried out by qualified service personnel.
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
