Johnston VT501 - Remove and Refit Procedures

MA7:1
V Range 501 l 651 l 801 Maintenance Manual
CHAPTER
7
Johnston Sweepers Limited
Remove and Refit Procedures
Chapter - Remove and Refit Procedures
All Copyright and rights are the property of Johnston Sweepers Ltd
Table of Contents
Section Pages
Removal and Refitting Instructions
Water Pump VT & VS 7 : 2
Wide Sweep Brush Motor VT & VS 7 : 3
Channel Brush Motor VT & VS 7 : 3
Channel Brush Cylinder VT & VS 7 : 4
Body Lifting or Removal VT & VS 7 : 4
Hydrodrive Gearbox & Pumps VS Only 7 : 5
Fan Drive Motor VS Only 7 : 5
Radiator VT Only 7 : 6
Fan Impeller VT Only 7 : 6
Fan Case VT Only 7 : 6
Gearbox Removal & Overhaul VT Only 7 : 7
Checking condition of Gearbox Casing VT Only 7 : 8
Fluid Drive Coupling VT Only 7 : 9
Gearbox Assembly VT & VS 7 : 10
