V Range 501 l 651 l 801 Maintenance Manual
MA4:12
Chapter - Water System
Page Issue B
Item Number Quantity Part Number Description
19 1 283701-19 Woodruff Key
20 3 283701-20 Connecting Rod
24A 3 283701-24A Ceramic Liner
31,32,40,49,50 1 Kit 283701-500 Plunger Seal kit - for 3 plungers
34,35,36,37,38 1 Kit 283701-501 Valve Kit - for the 6 valves
Exploded View of Pump
