Johnston VT501 - Standard Repair Times (SRT)

All Copyright and rights are the property of Johnston Sweepers Ltd
MA1:5
V Range 501 l 651 l 801 Maintenance Manual
Johnston Sweepers Limited
Chapter - Scheduled Maintenance
Area Remove / Ret Time Taken
(Mins)
Special Tools
Required
1 or 2
Persons
Hopper Side Locker Door 10 none
1
Hopper Side Locker Gas strut 10 none
1
Hopper Side Locker door catch mechanism 10 none
1
Hopper Side Door (each) 10 none
1
Hopper Side Door Seal (each) 25 none
1
Hopper Side Door lock and catch (each) 15 none
1
Hopper Mesh Screen (each) 10 none
1
Hopper Body Tip Cylinder 60 none
1
Hopper Body tip Hinges 120 none
1
Hopper Door Lock Hydraulic cylinder 25 none
1
Hopper Door Lock Proximity switch (each) 10 none
1
Hopper Rear Door Chute plate 30 none
1
Hopper Wear Plate (each). 30 none
1
Hopper Intake Duct 45 none
1
Hopper Centre Bafe (Dual machines only). 15 none
1
Hopper Rear Door 70 none
1
Hopper Rear Door Cylinder 35 none
1
Hopper Rear Door Seal 30 none
1
Hopper Fan Case Seal 20 none
1
Hopper Cowl Seal 45 none
1
Hopper Cowl NAF 90 none
1
Hopper Intake duct ap air cylinder 15 80 bar Pressure
1
Hopper Intake duct ap Actuator 10 none
1
Hopper Intake duct ap 10 TB1556 1
Hopper Intake duct ap Shaft 60 none 1
Hopper Flap shaft bush (inside body) 30 none
1
Hopper Flap shaft bearing (outside body) 15 none
1
Subframe Body tip mount. 40 none
1
Subframe Water lter assembly 30 none
1
Subframe Body prop 15 Workshop body prop
PN:7030765
1
Subframe Body prop release assembly 25 none
1
Used oils and filters should be disposed of in accordance with the local
waste disposal regulations.
These procedures should be carried out by qualified service personnel.
This Guide Detail the time taken to remove, ret and validate the item listed. Where the task is listed as 2
person the total time taken is shown in the table however certain aspects of the tasks may require 2 persons
for the safe completion of the task.
Page Issue B
STANDARD REPAIR TIMES (SRT)
