MA5:1
V Range 501 l 651 l 801 Maintenance Manual
CHAPTER
5
Johnston Sweepers Limited
Pneumatic System
Chapter - Pneumatic System
All Copyright and rights are the property of Johnston Sweepers Ltd
Table of Contents
Section Page
Introduction
General Description 5 : 2
Circuit Pressures 5 : 2
Pneumatic Pipe Colours 5 : 2
Valve Identification/Location 5 : 3
Component Removal
Air Filtration and Regulator (FR) 5 : 4
Pneumatic Valve Island 5 : 4
Indicator Status 5 : 5
Pneumatic Valve Island - Modus Operandi 5 : 6
Circuit Diagrams 5 : 7
Page Issue A
