V Range 501 l 651 l 801 Maintenance Manual
MA3:14
Chapter - Electrical System
Page Issue B
F1
F2
F3
F4
F4
09:45
20.01.2016
1.04
0
48
1.4 Service Hours
F1
F2
F3
F4
F4
09:45
20.01.2016
1.05
1.5 USB Download
(Data Capture)
Insert an Johnston
approved USB stick
into the USB port
(located on front of
the JVM - bottom left
hand side).
Press centre button
on JVM to download.
Key to Logging Screen Icons
Vehicle Logging (continued)
1. Engine Hours
2. Average Engine - RPM
3. Total Distance - Swept
4. Fuel Consumption
5. Average Fuel Consumption
6. Engine Hours - To Next Service
7. Engine Hours - Since Next Service
12
3
6
5
ø
ø
MIN
4
7
