V Range 501 l 651 l 801 Maintenance Manual
MA8:14
Chapter - Fault Diagnosis
Page Issue A
Code Type Description of Fault
4096 Engine Fault (85kW Engine only) Low Oil Pressue
4097 Engine Fault (85kW Engine only) Low Oil Level
4098 Engine Fault (85kW Engine only) Coolant Temp High
4099 Engine Fault (85kW Engine only) Loss of Speed Signal
4100 Engine Fault (85kW Engine only) Water in Fuel
4101 Engine Fault (85kW Engine only) Coolant Temp Shutdown
4102 Engine Fault (85kW Engine only) Low Fuel Shutdown
EMCY
Code Type Description of Fault
System Locker Node - ID 16
Area of Fault
PowaPak Node - ID 22
Area of Fault
Hydrostatic Node - ID 24
Area of Fault
Hopper Node - ID 18
Area of Fault
36881 Digital Output 10 Short to ground Gutter Spray 1 Not Used Used as Input Supawash
36882 Digital Output 11 Short to ground CB 2 Water Used as Input Hydrostatic Reverse Output Used as Input
36883 Digital Output 12 Short to ground Gutter Spray 2 Ignition Output Aux engine Gearbox Sensors Output Used as Input
36884 Digital Output 13 Short to ground Nozzle 1 Water Combivak Nozzle #1 Not Used Used as Input
36885 Digital Output 14 Short to ground Nozzle 2 Water Combivak Nozzle #2 Fan Control Used as Input
36886 Digital Output 15 Short to ground Body Discharge Work Lamp RH Work Lamp RH Auto Lube Power
36887 Digital Output 16 Short to ground Additional Water Work Lamp LH Work Lamp LH External Discharge Pump Run
36896 Analogue Output Short to ground WSB Balance Regulator LH WSB Balance Regulator RH WSB Balance Regulator RH Not Used
36897 H-Bridge Output Short-Circuit Rear Warning/Work Lights Not Used Not Used Powaboom Raise/Lower
Truck Mounted Sweepers 85kW Engine Specific
Revision 04 Release Date: 10.04.2014
Note: All of the Codes below are displayed on page 4.8
Truck Mounted Sweepers Emergency (EMCY) Codes (continued)
Revision 04 Release Date: 10.04.2014
