5
4.2 Size of Main Machine and Accessories
4.2.1 Size of Main Machine
261
280
211
166
Figure 2
4.2.2 Size of Mounting Plate
260
24
165
9.5
226
130
90±0.2
228±0.2
4×M8
Figure 3
