4 . Function Mode Functions
4
.
1 Dual Rate, Ex
p
onential
(
Function Mode
)
Dual rates are available for the aileron, elevator and rudder
channels of your R/C helicopter . The amount of travel is
adjustable from 0-1 2 5%; exponential is adjustable from 0% (LIN)
to 1 00% in 1% increments. The factor y setting, or default value,
for both the 0 and 1 switch positions is 1 00%. Either switch
position may be selected as the low or high rate by placing the
switch in the desired position and adjusting the value
accordingly . There is also an automatic dual rate setting for all
three channels, operable from the Flight Mode Switch.
Dual rates can be defined as the ability to var y the travel or
throw rate of a ser vo from a switch. Due to dif fering travel rates,
you will find that the sensitivity of the control either increases or
decreases accordingly . A higher rate, or travel, yields a higher
overall sensitivity . Y ou may find it easier to think of the Dual Rate
Function as double-rated or half-rates.
The Dual Rate Function works in conjunction with the Exponential
Function to allow you to precisely tailor your control throws.
In Function Mode, use the UP or DN key to select Dual Rate and
access by pressing the UP and DN keys simultaneously .
AILE Aileron
ELEV Elevator
RUDD Rudder
AUTO auto dual rate
RUDD auto exponential
Dual rate switch
p
osition
Press the UP and DN keys
simultaneously to enter/exit
the Function Mode
Press the DN and Select key
s
simultaneously to access th
e
Function Mode list dis
p
la
y
To Reverse Switch
UP
DN SELECT CH CH CLEAR
Reset Dual Rate
function
Function Select
(
dual rate o
r
Channel Selection Increase o
r
V
alue to 100%
To Serv o Output
Indicato
r
ex
p
onential
)
(Aile, Ele
v
, Rudd,
A
uto Rudd
)
decrease Dual
Rate
V
alue
HELI 73
