JRC JAN-9202 - User Manual

Other manuals for JRC JAN-9202

Field Service Manual1078 pages

Installation Manual100 pages

Questions and Answers

K
Karen MunozNov 25, 2025
How do I fix JRC Monitor when the azimuth of the Gyro compass is not displayed?
- J
  Jenna LopezNov 25, 2025
  If the azimuth of the Gyro compass isn't displaying correctly on your JRC Monitor, or the rotation direction is wrong: * Verify that the communication is set correctly. * Ensure the power supply for the Gyro compass equipment is turned on. * Check the connection with the Gyro compass equipment, looking for the LED indicator at signal reception if connected to the serial LAN or gyro interface circuit. * If using the serial-LAN interface circuit (CMH-2370), confirm its power supply is on. * If using the Gyro interface circuit (CMJ-554), ensure it is set correctly and check its fuse. If the issue persists, the serial-LAN interface circuit (CMH-2370), the Gyro interface circuit (CMJ-554), internal wiring, or the central control unit (NDC-1590) may be faulty, requiring a repair requ...
D
daniel02Aug 23, 2025
What to do if position information (GPS) is not displayed on JRC Monitor?
- C
  Christopher PerezAug 23, 2025
  If the GPS information isn't showing on your JRC Monitor, verify these items: 1. Ensure the communication is correctly set. 2. Check that the power supply for the GPS equipment is on. 3. Confirm the GPS equipment is performing positioning. 4. Verify the connection with the GPS equipment, checking the LED of the corresponding port if connected to the serial LAN interface circuit. 5. If connected to the serial-LAN interface circuit (CMH-2370), ensure its power supply is on. If problems persist, the serial-LAN interface circuit (CMH-2370), internal wiring, or the central control unit (NDC-1590) might be faulty, requiring a repair request from the distributor.
K
Krista RomeroAug 25, 2025
Why is my JRC Monitor screen not displaying even though the power is on?
- M
  Mr. Jesse FitzpatrickAug 26, 2025
  If your JRC Monitor has power but the screen remains blank, first, check the brightness setting and adjust it to an appropriate level. If adjusting the brightness doesn't solve the problem, the internal wiring or the display unit (NWZ-208/ NWZ-207/NWZ-214) may be faulty, and you should request a repair from the distributor.
J
joshua90Aug 27, 2025
Why is the Log not displayed correctly on my JRC Monitor?
- D
  Dawn SmithAug 27, 2025
  If the log isn't displayed correctly on your JRC Monitor, ensure the communication is set correctly. Also, check that the power supply for the log equipment is turned on and verify the connection with the log equipment, looking for the LED blinking at signal reception if connected to the serial LAN interface circuit or gyro interface circuit.
A
Andrew PhillipsAug 28, 2025
How to troubleshoot rudder angle display issues on JRC Monitor?
- A
  Aaron SimmonsAug 28, 2025
  If the rudder angles are not displayed correctly on the JRC Monitor, verify that the communication is correctly set. Also, ensure that the power supply for the rudder angle indicator is turned on and check the connection with the rudder angle indicator, looking for the LED at data reception if connected to the serial LAN interface circuit. If connected to the serial-LAN interface circuit (CMH-2370), ensure its power supply is on.
M
Matthew ThomasSep 18, 2025
Why is my JRC Monitor display frozen?
- G
  garciatimothySep 18, 2025
  If your JRC Monitor's display is frozen, preventing access to the task menu, the central control unit (NDC-1590) may be abnormal, and you should request a repair from the distributor.
G
gdaySep 14, 2025
What does it mean when JRC Monitor displays 'Sub LAN is disabled'?
- J
  Jose HarperSep 15, 2025
  If the JRC Monitor displays the popup 'Sub LAN is disabled. This system is operating with Main LAN only,' it indicates a network failure has occurred on the sub LAN. Make a request to the distributor for repair.
J
jennifer26Sep 16, 2025
What to do when JRC Monitor shows 'Main/Sub LAN is disabled'?
- B
  Brandon HardinSep 16, 2025
  If your JRC Monitor displays the popup 'Main/Sub LAN is disabled. This system is operating with serial in CCU only,' it means a network failure has occurred on both the main and sub LANs. Make a request to the distributor for repair.
J
jose66Sep 7, 2025
Why are contact signals not outputting from my JRC Monitor?
- J
  John CrawfordSep 7, 2025
  If contact signals are not outputting from your JRC Monitor, and the signal output is acquired from the serial-LAN interface circuit, ensure the power supply for the serial-LAN interface circuit (CMH-2370) is turned on. If the problem persists, the serial-LAN interface circuit (CMH-2370) may be faulty, and you should request a repair from the distributor.
H
Hailey DrakeSep 4, 2025
Why can't I adjust the brightness on my JRC Monitor?
- S
  Sheila TaylorSep 4, 2025
  If you cannot adjust the brightness of your JRC Monitor, the display unit (NWZ-208/ NWZ-207/NWZ-214) may be faulty, and you should request a repair from the distributor.

Summary

Section 2 Name and Function of Each Unit

2.1 Name and Main Function of the Operation Unit

Details the names and primary functions of the operation unit components.

2.2 Names and Main Functions of the Top Screen

Section 3 Basic Operations

3.1 Powering On and Starting

Details the procedure for powering on and starting the equipment.

3.2 Starting Each Mode

3.3 Basic Operations when using a Trackball

Describes the fundamental operations performed using the trackball.

3.4 Basic Menu Operations

Section 6 Setting Up Alerts

6.1 Selecting Setting Items

6.2 Depth;Safety Contour Alert Generation Conditions

Defines the conditions for generating Depth Below Keel alarms.

6.3 Position Integrity Alert Generation Conditions

Sets conditions for position monitor warnings and HDOP limit cautions.

Section 7 Setting Up the Operation Mode

7.1 Basic Operation of the [Settings] Dialog Box

Explains the fundamental operations within the Settings dialog box.

Section 8 Adjusting and Setting Up Equipment (for Services)

8.1 Service Menu

8.2 Verifying Installation and Initial Setting

Guides on verifying installation and performing initial settings using the Installation dialog.

8.2.3 Setting a Serial Port

8.2.4 Setting ships parameters

Section 9 Maintenance & Inspection

9.1 Maintenance Functions Executed from Menu

9.4 Performance Check

9.5 Replacement of Major Parts

9.6 Software Update

Explains the procedure for updating the equipment's software.

9.7 Firmware Update

Provides instructions for updating the product's firmware.

9.9 Data Backup;Restore

Details the procedures for backing up and restoring equipment data.

9.10 Recovery of the Images in the C Drive

Guides on recovering system images in the C drive, including OS and software recovery.

Section 10 Failures and After-Sale Services

10.1 Failure Detection

10.2 Countermeasures for Failures

10.3 Troubleshooting

Offers solutions for common symptoms and causes of equipment malfunction.

Section 12 Specifications

12.1 JAN-9202

Lists the general specifications for the JAN-9202 model.

12.2 JAN-7202

Lists the general specifications for the JAN-7202 model.

12.3 Display Unit

12.4 Central Control Unit

12.5 Power Supply Unit

12.6 Trackball Operation Unit

Appendix A Alert List

A.1 Alarms

Lists and describes various alarm types, their class, color, status, and sound.

A.2 Warnings

Details warning messages, their subjects, explanations, and categories.

A.3 Cautions

JRC JAN-9202 Specifications

General

Type	X-band Radar
Power Supply	24 V DC
Transmitter Output Power	25 kW
Range	Up to 96 NM
Display	LCD
Power Output	25 kW
Frequency	9410 MHz ± 30 MHz
Antenna Rotation Speed	24 rpm
Beam Width	1.2°
