1.Introduction
1-2
1.3 Components
This section lists the components.
Standard Equipment
Name Type No. Qty. Remarks
Display unit NWZ-1650-E 1 Flash Mount Type
Processing Unit NQA-4327 1
Display-LAN Cable CFQ-7540 1 Display-Processing unit
Matching box(Primary)
NQD-2597 1
200kHz
NQD-2598 1
50KHz
Transducer(Primary)
NKF-349 1
200kHz (with cable 20,30,40,50m)
NKF-350 1 50kHz (with cable 20,30,40m)
Spare parts 7ZXNA2012 1
Fuse×2,
Instruction manual 7ZPNA2051 1
Option
Name Type No. Remarks
Matching box
(secondary)
NQD-2597 200kHz
NQD-2598 50kHz
AW-154F 200kHz
AW-154F-50 50kHz
Transducer (secondary)
NKF-349 200kHz (with cable 20,30,40,50m)
NKF-350 50kHz(with cable 20,30,40m)
NKF-341 200kHz (with cable 20,30,40,50m)
NKF-345 50kHz (with cable 20,30,40m)
Gate valve transducer
NKF-394 200kHz (with cable 20,30,40,50m)
NKF-396 50kHz (with cable 20,30,40m)
3817.0016 Alphatron Gate valve for 50kHz LR
3817.0018 Alphatron Gate valve for 200kHz LR
3817.0034 Alphatron Gate valve for 50kHz DNV
3817.0032 Alphatron Gate valve for 200kHz DNV
3817.0028 Alphatron Gate valve for 50kHz BV
3817.0026 Alphatron Gate valve for 200kHz BV
3817.0022 Alphatron Gate valve for 50kHz ABS
3817.0020 Alphatron Gate valve for 200kHz ABS
Spare parts
7ZXNA2009 Fuse×2, Printer paper×1
7ZXNA2010 Fuse×2, Printer paper×4
7ZXNA2011 Fuse×2, Printer paper×10
Junction Box JB-340 for junction
Output buffer NQA-4351 12ch buffer unit
Remote display NWZ-4610 Remote display for Depth data
Dimmer unit NCM-227 for remote display
AC power rectifier NBA-5143 for remote display
Printer NKG-901 External printer
Printer wall mount bracket MPBP32159A Wall mounting for NKG-901 Printer
Printer cable 7ZCJD0254A Length1.5m
Printer cable 7ZCJD0270B Length10m
Desktop Kit MPBX50347 For NWZ-1650
