5. Maintenance & Check
5-2
5.3 Maintenance Function
Touch Panel Calibration
Refer to "Touch Panel Calibration" in 4.5 Initial Setting.
Displaying System No.
Refer to 4.7 Checking system version.
5.4 Replacing Printer Paper (When NKG-901 printer is installed)
Do not cut your hand in the blade tip of the paper cutter.
Name Model type Remarks
Printer paper H-7ZPJD0384 TF50KS-E2D for NKG-901 printer
◎After turning off the power supply of this equipment, exchange papers.
On NKG-901 when the printer cover is opened while turning on, the alert of “NO PAPER" sounds.
① Open the paper cover by pressing the paper cover opening button.
② Set the paper like the direction of figure.
③ Shut the cover after making the paper tip put out outside of the printer and pushing both ends of the
upper paper cover.
＊A red mark of a paper slip previous notice puts out from 1m remain when the remainder of the paper
decreases.
To Next Page
