JRC JFE-400 User Manual

4. Operation
4-33
* Responsibility Transfer function are available when connected to the CAM(Central Alert Management) system.
The details of each alert are as follows.
No. Name Raising Rectification Support information
1 DEPTH ALERT Depth becomes below the set value Depth exceed the set value Sail toward depth area deeper
than current position
2 LOST DEPTH Sea bottom tracking is unavailable Bubbles is clear Confirm a depth on chart
3 NO PAPER Out of paper Refill a paper Refill a paper
4 LOST PRINTER Cannot communicate to printer Replace a printer Contact us or your agency
5 WEAK ECHO TX Echo transmission level is low Echo transmission level is normal Contact us or your agency
6 WEAK ECHO RX Echo receiving level is low Echo receiving level is normal Contact us or your agency
7 LOST PROCESSOR Cannot communicate to processor
unit
Restore communication to
processor unit
Check network cable and
connection
8 LOG MEMORY FAIL Cannot access internal memory Replace a processor unit Contact us or your agency
Alert icon and status
The icon of the alert changes depending on the situation and status. JFE-400/700 Echo Sounder uses the icons
in the table below.
No. Name of alert icon Functional outline Alert icon
1 Active - unacknowledged alarm A flashing red triangle.
A symbol of loudspeaker in the middle of the triangle.
2 Active - silenced alarm A flashing red triangle.
A symbol as in icon number 1 with a prominent diagonal line above it.
3 Active - acknowledged alarm A red triangle.
An exclamation mark in the middle of the triangle.
4 Rectified – unacknowledged alarm A flashing red triangle.
A tick mark in the middle of the triangle.
5 Active - unacknowledged warning A flashing yellowish orange circle.
A symbol of loudspeaker in the middle of the circle.
6 Active - silenced warning A flashing yellowish orange circle.
A symbol as in icon number 5 with a prominent diagonal line above it.
7 Active - acknowledged warning A yellowish orange circle.
An exclamation mark in the middle of the circle.
8 Active - responsibility transferred
warning
A yellowish orange circle.
An arrow pointing towards the right in the middle of the circle.
9 Rectified - unacknowledged warning A flashing yellowish orange circle.
A tick mark in the middle of the circle.
10 Caution A yellow square.
An exclamation mark in the middle of the square.
* Silenced and Responsibility Transferred function are available when connected to the CAM system.
