3. Display
3-1
3. Display Mode
3.1 Standard mode
Standard mode displays real time sounding echoes.
[Sample screen at dual frequency]
Display mode Depth display
Date
Time
LAT/LON
Range scale
Frequency and position
of transducer
Explanation of depth
Keel height value
Gain control
Depth
Note
・ By primary and secondary transducer setting, dual display data will change position.
・ FWD sounding data is displayed on the right side.
・ LAT/LON display needs to input position data.
