4. Operation
4-5
When it is a history mode
・ Whenever the is touched, the drawing time of the history is lengthened.
(five stages of 3hr→6hr→12hr→24hr→48hr)
・ Whenever the
is touched, the drawing time of the history is shortened.
(five stages of 48hr→24hr→12hr→6hr→3hr)
When menu is displayed
・ When the is touched, a set value is changed.
・ When the
is touched, a set value is changed.
Right and Left Key of Cursor [CURSOR]
When it is a history mode
・ When the
is touched, a position cursor is moved left, and it moves accelerating when keeping
touching it.
・ When the
is touched, a position cursor is moved right, and it moves accelerating when keeping
touching it.
・ Information of a time point to which a position cursor is displayed is displayed in the screen.
・ Display information: Depth/Draft/Keel correction/Date/Time/Latitude Longitude
・ The position where a position cursor is displayed doesn't scroll and is fixed. Therefore, when the history
screen scrolls, display information is updated.
・ When the position cursor is displayed, tap it in the history area to move the position cursor to that area.
・ When the key disappears, tap the screen to redisplay it.
When menu is displayed
・
： When submenu is displayed, returns to the previous menu.
