2-21
● Beacon Connection
■ JLR-4341 or JLR-4331 (DGPS Receiver) Connection
Use the option cable (CFQ-7250).
* Connecting JLR-4331 does not allow DGPS,
but allows receiving only meteorological information. (Refer to the following table.)
■ Beacon Receiver Connection
Modify the option cable (CFQ-7250).
■ Features and installation procedure for beacon receiver
* Refer to “5.3.7. Data I/O Settings (DATA I/O)” for installation.
Types of DGPS receivers
Competitor’s
Beacon receiver
JLR-4331
receiver
JLR-4341 receiver
Enhanced accuracy of
The position measured by
GPS compass (DGPS
conversion)
○ × ○
Receiving weather
information
○ ○ ○
Setting for
Data OUT4/IN4
Selecting beacon/**** allows
the DGPS receiver to be
used as a beacon receiver.
Selecting 4341/**** allows the
DGPS receiver to be used as a
beacon receiver.
Power
DC12V
CFQ-7250
JLR-4341 or JLR-4331
DPGS Receiver
3m
0.4m
14 Pin
6 Pin
Beacon
Receiver
Power
CFQ-7250
14 Pin
Input→
←Output
Data Common
Brown
Black
Divide the CFQ-7250
cable to use
Yellow
To Next Page
