JRC JLR-21 - Page 43

2-25
Option metal fittings (Stainless-steel) MPBP31612 Bundled list
Points book X 1 Metal fittings X 2
Ｍ８ Bolt
（ L=100,150 ）
X 2 pieces for
each
Flat washer X 4 Spring lock
washer X 2
Hex nut X 4
Select one about M8 volt length according to the diameter of the installed prop.
Metal fittings
M8 bolt
Flat washer
Flat washer
Spring
lock washer
Hex nut
Prop
Possible range
Φ27.2mm～Φ89.1mm
Junction Box NQE-7720(OPTION)
Seal processing is
effective.
