JUKI DDL-8000A Engineer's Manual

viii
CAUTION :
To avoid malfunction and damage of the machine, conrm the
following
.
• Clean the sewing machine thoroughly before using it for the rst time.
• Remove all dust collected on the sewing machine during the transportation.
• Conrm that the voltage and phase are correct.
• Conrm that the power plug is properly connected.
• Never use the sewing machine in the state where the voltage type is different from the designated one.
• The direction of rotation of the sewing machine is counterclockwise as observed from the hand-
wheel side. Be careful not to rotate it in reverse direction.
SAFETY DEVICES AND WARNING LABELS
CAUTION BEFORE OPERATION
*

The mounting location
and shape of the power
switch differs with the
place of destination.
Pulley cover
This is a cover for
preventing entangle-
ment of hands, hair
and clothes by the
hand pulley.
Power switch
This is a switch for disconnecting the
power unit of the sewing machine from
the power supply.
Selection of the power switch (EU type)
Be sure to use the IEC60204-1-compli-
ant power switch with rated current of
20A or more and short-circuit breaking
capacity of 120 A or more.
Warning label
against pinching
This label warns
thar fingers or other
parts of human body
can be pinched in
the thread take-up
lever.
Thread take-up lever
cover
This is a cover for pre-
venting contact between
the human body and the
thread take-up lever.
Power switch
This is a switch for
disconnecting the power
unit of the sewing ma-
chine from the power
supply. (Sewing machine
for export in general and
for China type)
Warning label
against pinching
This is the caution
label to protect fin
gers, etc. from being
caught between the
bed and table during
maintenance.
Warning label
(Refer
to the
warning
label on
page i.)
The label gives
the minimum
precautions to
be taken when
operating the
sewing machine.
High-voltage
caution label
This label warns
that there is a
high-voltage part
inside cover.
Finger guard
This is a cover for
preventing contact
between fingers
and the needle.

JUKI DDL-8000A Specifications

General

Stitch Type	Lockstitch
Motor Type	Direct-drive motor
Thread Trimmer	Automatic
Max. Stitch Length	5mm
Needle Bar Stroke	30.7mm
Lift of the Presser Foot	By hand: 5.5mm, By knee: 13mm
Control Panel	Digital
Lubrication	Automatic
