– 93 –
No. Item Description Setting range
Setting
levle
Default
*
P150 REVERSE signal off
time
Time from the BT SW being turned off to reverse signal being stopped
2 to 500
(ms)
S 2
P151 ON/OFF of the bird's
nest preventing
operation
(Bird's nest)
ON/OFF of the bird's nest preventing operation is set with this function setting
item.
0 to 1
(–)
U 0
P152 Waiting time until the
wiper cylinder starts
operation
(Bird's nest)
Sets the time to wait for starting wiper cylinder operation.
0 to 990
(ms)
S 110
P153 Wiper cylinder ON
time
（
(Bird's nest)
Sets the time duration of the wiper cylinder being ON.
0 to 990
(ms)
U 150
P154 Time until sewing
starts after turning
OFF the wiper
cylinder
(Bird's nest)
The waiting time required until the sewing machine starts the next sewing
after turning OFF the wiper cylinder is set with this function setting item.
0 to 990
(ms)
S 30
P155 Wiper output duty (Bird's nest)
ON duty of the wiper output is set with this function setting item.
0 to 100
(%)
S 90
P159 Suction ON/OFF (Bird's nest) ON/OFF of the suction device is set with this function setting
item.
0 to 1
(–)
S 1
P160 Suction time (Bird's nest)
Sets the time duration of suction.
5 to 5000
(ms)
S 500
*
P161 Presser lifting
operation at holding
thread ON/OFF
ON / OFF of the presser lifting operation when clamping the thread is set with
the function setting item.
0 :
Activates the lifting operation.
1 :
Deactivates the lifting operation.
0 to 1
(–)
U 0
*
P162 Angle at start of
presser lifting
operation starts
when the thread is
held
Setting of presser lifting amount at holding thread
0 to 359
(°)
U 100
*
P163 Ending angle of soft
start for the thread
clamp
The ending angle of the soft start for the thread clamp is set with this function
setting item.
0 to 720
(°)
U 340
*
P164 Setting of presser
lifting amount at
holding
thread
The amount of lift of the presser foot when clamping the thread is set with this
function setting item. 0 to 500
(–)
U 50
*
P165 Presser lifting
operation time when
the thread is held
Sets the presser lifting operation time when the thread is held.
1 to 990
(ms)
U 20
*
P166 1st electric current
time for thread
clamp
Period of time during which the 1st electric current is fed applied to the thread
clamp is set with this function setting item.
Time from the thread presser being activated to the second current value
being changed
1 to 990
(ms)
U 7
*
P167 2nd electric current
value for thread
clamp (ON duty)
“ON duty” is set in order to determine the 2nd electric current value of the
thread clamp
Current value to which the value changed after the thread presser is activated
and (P166) passes
1 to 100
(%)
U 69
*
P168 BT initial on time Time from BT solenoid being activated to brake applied (before stroke end)
1 to 200
(ms)
S 15
*
P169 Buffer brake time at
BT on
Time duration of BT solenoid brake being applied (before stroke end)
1 to 200
(ms)
S 40
*
P170 Buffer brake Duty
setting at BT off
Current value when the solenoid for impact absorbing is restarted (brake).
1 to 200
(%)
S 100
＊
Supplementary explanation is added in 4.-(2) Further information about memory switch.
◎
These data are stored in the main board in the control box. Data other than these data are stored in the panel board in the panel.
