– 94 –
Table 2 Panel function setting items
No. Item Description Setting range
Setting
level
Default
J04 Voice language
selection
Selects a voice language.
1 : Chinese
2 : English
1 to 2
(–)
U 2
J05 Voice ON/OFF Selects the voice guidance ON or OFF.
0 : All voice guidance OFF
1 : Only panel operation guidance
2 : All voice guidance ON
0 to 2
(–)
U 2
J10 Back light
brightness
Sets the back light brightness. 1 to 3
(–)
U 3
J11 Energy-saving
mode
Sets the deactivation time of the LCD back light when no operation is
conducted.
0 : Back light always activated
1
to 20 :Time until the light is turned off
0 to 20
(sti/min)
U 0
J14 Password If the password is set to a value other than "0000", the password input screen
is displayed before the memory switch change screen is displayed by holding
down the M switch.
★
This data is not initialized with P70.
0000 to 9999
(–)
S 0
Table 3 Sewing machine monitoring items
No. Item Description Setting range
Setting
level
Default
N01 Main software
version
Displays the main software version.
– U –
N02 Panel software
version
Displays the panel software version.
– U –
N03 Sewing machine
speed monitor
Measures the sewing machine speed and displays it.
– S –
N04 Input value of
pedal A/D
Displays the input value of pedal A/D.
– S –
N05 Display of principal
axis angle
Displays the angle when the up stop position is zero degree.
– S –
N06 Display of principal
axis angle
Displays the angle when the down stop position is zero degree.
– S –
N07 Supply voltage A/D
value
Displays the A/D value of the supply voltage.
– S –
N14 T-motor software
version
Displays the version of the step motor (presser lifter motor) control software.
– U –
N15 Grease-up stich
count
Counts the number of stiches to inform you of grease-up timing.
Selection of "0" clears the counter.
(Unit: x100,000 stitches)
The grease-up warning, "E220", is generated at 8 hundred million stitches.
The grease-up error, "E221", is generated at 9 hundred million stitches.
– S –
