JUKI DDL-8000A Engineer's Manual

– 77 –
(When a cable clip band is not available right now)
1.
Pull out the panel cable not to it in the arm.
2.
Lay the redundant part of the cable under the
cable coming out from the panel.
3.
Put the protruding cable into the hole of the side
plate.
Do not slack the cable.
Lay the cable under this cable.
Put the cable into the hole of the side plate.

JUKI DDL-8000A Specifications

General

Stitch Type	Lockstitch
Motor Type	Direct-drive motor
Thread Trimmer	Automatic
Max. Stitch Length	5mm
Needle Bar Stroke	30.7mm
Lift of the Presser Foot	By hand: 5.5mm, By knee: 13mm
Control Panel	Digital
Lubrication	Automatic
