JUKI IT-100 User Manual

– 42 –
31 Number of stitches of
reverse feed stitching
on the way
Number of stitches of reverse feed stitching on the way.
0 to 19
(Stitches)
N-OBT
32 Effective condition
of reverse feed
stitching on the
way when the
sewing machine is
stopping.
Effective condition of reverse feed stitching on the way
0 : Function is not operative when the sewing machine stops.
1 : Function is operative when the sewing machine stops.
0/1
OBTS
33 Thread trimming
function by reverse
feed stitching on
the way
Thread trimming function by reverse feed stitching on the way
0 : Automatic thread trimming function after completion of re-
verse feed stitching on the way is not operative.
1 : Automatic thread trimming after completion of reverse feed
stitching on the way is performed.
0/1
OBTT
*
35 Sewing speed at a
low speed
Lowest speed by pedal
(The MAX value differs by machine head.)
150 to MAX
(sti/min)
S-POS
*
36 Sewing speed of
thread trimming
Thread trimming speed
(The MAX value differs by machine head.)
100 to MAX
(sti/min)
S-TRM
37 Sewing speed of
soft-start
Sewing speed at the start of sewing (soft-start)
(The MAX value differs by machine head.)
100 to MAX
(sti/min)
S-SOFT
38 One-shot speed One-shot speed (The max. value depends on the sewing speed of
the sewing machine head.)
150 to MAX
(sti/min)
S-ASS
*
39 Pedal stroke at the
start of rotation
Position where the sewing machine starts rotating from pedal neutral
position (Pedal stroke)
10 to 50
(0.1 mm)
P-SSP
*
40 Low speed section
of pedal
Position where the sewing machine starts accelerating from pedal
neutral position (Pedal stroke)
10 to 100
(0.1 mm)
P-LSA
*
41 Starting position of
lifting presser foot
by pedal
Position where the cloth presser starts lifting from pedal neutral posi-
tion (Pedal stroke)
– 60 to –10
(0.1mm)
P-FLW
*
42 Starting position of
lowering presser
foot
Starting position of lowering presser foot
Stroke from the neutral position
8 to 50
(0.1 mm)
P-FLD
*
43 Pedal stroke 2 for
starting thread
trimming
Position 2 where the thread trimming starts from pedal neutral posi-
tion (When the function of lifting presser foot by pedal is provided.)
(Pedal stroke)
(Effective only when Item No. 50 is set at 1.)
– 60 to –10
(0.1 mm)
P-TRM2
*
44 Pedal stroke
for reaching the
maximum sewing
speed
Position where the sewing machine reaches its highest sewing
speed from pedal neutral position (Pedal stroke) 10 to 150
(0.1 mm)
P-MAX
*
45 Compensation of
neutral point of the
pedal
Compensation value of the pedal sensor
–15 to 15
P-ANP
47 Auto-lifter selecting
function
Limitation time of waiting for lifting solenoid type auto-lifter device
10 to 600
(second)
T-FL
*
48 Pedal stroke 1 for
starting thread
trimming
Position where thread trimming starts from pedal neutral position
(Standard pedal) (Pedal stroke)
(Effective only when Item No. 50 is set at 0.)
– 60
to – 10
(0.1 mm)
P-TRM1
49 Lowering time of
presser foot
Sets the time required until the lowering of the presser foot is com-
pleted after a depress on the pedal
0
to 500
(10 ms)
T-FLWT
50 Pedal specication Type of pedal sensor is selected.
0 : KFL
1 : PFL
0/1
PFL
51 Compensation of
solenoid-on timing of
reverse feed stitching
at the start of sewing
Compensation of starting the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
– 36 to 36
(10°)
T-SON
52 Compensation of
solenoid-off timing of
reverse feed stitching
at the start of sewing
Compensation of releasing the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
– 36 to 36
(10°)
T-SOFF
53 Compensation of
solenoid-off timing of
reverse feed stitching
at the end of sewing
Compensation of releasing the solenoid for reverse feed stitching
when reverse feed stitching at the end of sewing is performed.
– 36 to 36
(10°)
T-EOFF
55
Foot lift after thread
trimming
Function of lifting presser foot at the time of (after) thread trimming
0 : Not provided with the function of automatic lifting of work-
clamp after thread trimming
1 : Provided with the function of lifting presser foot automatically after
thread trimming
0/1
FLAT
56
Reverse revolution
to lift the needle after
thread trimming
Function of reverse revolution to lift the needle at the time of (after)
thread trimming
0 : Not provided with the function of reverse revolution to lift the
needle after thread trimming
1 : Provided with the function of reverse revolution to lift the
needle after thread trimming
0/1
RATRM
No. Item Description Setting range Indication of function setting
* Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
