JUKI LBH-1790 - Vector Parameter List

– 128 –
31-2 Vector parameter list
No. Item Setting range Edit unit Initial display
Knife groove width, right -2.00 to 2.00 0.05mm 0
Knife groove width, left -2.00 to 2.00 0.05mm 0
With/without knife 0 to 1 --- 0
Max. speed limitation 400 to 4200 100rpm ---
1st clearance compensation -9 to 9 1 stitch 0
2nd clearance compensation -9 to 9 1 stitch 0
Increase/decrease ratio (X direction) 20 to 200 1% 100
Increase/decrease ratio (Y direction) 20 to 200 1% 100
ACTIVE tension reference value 0 to 200 1 0
