JUKI LBH-1790 User Manual

– 15 –
4. HOW TO USE THE PEDAL
This sewing machine can be used by selecting the pedal operating procedure from among 3 types described
later.Selecttheoperatingprocedureyoudesireforworkingefciencyandusethesewingmachine.
4-1 Setting procedure of the pedal type
1
Call the pedal type setting parameter.
Hold pressing switch (A) for 6 seconds
and memory switch (level 2) button (B) is
displayed on the screen. When this button is
pressed, the memory switch (level 2) list screen
is displayed.
Press button K01 (C) of the pedal type
selection parameter on the memory switch (level
2) list screen and the pedal type change screen is
displayed.
A
B
C

JUKI LBH-1790 Specifications

General

Stitch Type	Lockstitch
Max Sewing Speed	4, 200 sti/min
Needle Bar Stroke	34.6 mm
Type	Industrial
Needle	DPx5
Motor	Servo Motor
Buttonhole Length	8 mm ~ 40 mm
