JUKI LBH-1790 - Changing Sewing Data; Default Initial Sewing Data

– 37 –
15. CHANGING SEWING DATA
15-1 Initial sewing data at the time of your purchase
Patterns from 1 to 10 have been already registered at the time of your purchase. The initial values of the
square type shape which are different in the cloth cutting length only have been inputted in the sewing data.
→
For the initial values of the square type shape, refer to “13. INITIAL VALUE DATA FOR EACH SHAPE
TABLE” in the Instruction Manual supplied with the device.
Pattern No. Cloth cutting length
1 6.40 mm (1/4")
2 9.50 mm (3/8")
3 11.10 mm (7/16")
4 12.70 mm (1/2")
5 14.30 mm (9/16")
6 15.90 mm (5/8")
7 17.50 mm (11/16")
8 19.10 mm (3/4")
9 22.20 mm (7/8")
10 25.40 mm (1")
