– 13 –
Button and display Description
A NUMBER OF TIMES OF BASTING
display
Number of times of basting which is set to the pattern data during
sewing is displayed.
B PATTERN NAME display Pattern name which is set to the pattern data during sewing is
displayed.
C WITH/WITHOUT DOUBLE
STITCHING display
With/without double stitching which is set to the pattern data during
sewing is displayed.
D KNIFE CANCEL button Every time this button is pressed, dropping of knife and non-dropping
of knife can be changed over alternately.
E PRESSRER DOWN button Presser can be lowered and the knife down screen is displayed.
To raise the presser, press the presser up button displayed in the
presser down screen.
＊
When performing threading in this state, turn OFF the power before
performing.
F BOBBIN WINDER button
Bobbin thread can be wound.
→
Refer to
11. WINDING BOBBIN THREAD, p.29
.
G PATTERN NO. display Pattern No. during sewing is displayed.
H STEP STITCHING button
When this button is pressed, the screen of step stitching to check
needle entry point and to perform re-sewing is displayed.
→
Refer to
10. PERFORMING RE-SEWING, p.27
.
I NEEDLE THREAD TENSION button
Needle thread tension which is set to the pattern data during sewing is
displayed, and when this button is pressed, the needle thread tension
change screen is displayed.
→
Refer to
9. CHANGING NEEDLE THREAD TENSION, p.25
.
J NUMBER OF TOTAL STITCHES
display
Number of total stitches of the pattern data during sewing is displayed.
K OVEREDGING WIDTH, LEFT display Overedging width, left which is set to the pattern during sewing is
displayed.
L1 COUNTER VALUE CHANGE button
Existing counter value is displayed on this button. When the button is
pressed, the counter value change screen is displayed.
→
Refer to
12. USING COUNTER, p. 30
.
L2 COUNTER CHANGE OVER button
Display of sewing counter/No. of pcs. counter can be changed over.
→
Refer to
12. USING COUNTER, p. 30
.
To Next Page
