5 Setup software
106
The next steps depend on which interface or type of connection has been
selected.
TCP/IP PORT The following parameters must be selected.
Analog
modem /
ISDN
The following parameters must be selected.
IP address /
HOST name
xxx.xxx.xxx.xxx
(Example: 10.11.2.100)
Enter the IP address of
your device. If you enter
the name, the IP
address can be
determined by clicking
on the button “Convert
HOST name to IP
address”.
Port number,
port name
502 The port used for
communication.
Communication
protocol
Modbus TCP/IP,
Modbus protocol
Modbus TCP/IP must
be set here.
Telephone number Enter the telephone
number for the required
device.
Connect via Select the modem that
is to be used to make
the connection.
Communication
protocol
Modbus TCP/IP,
Modbus protocol
Modbus protocol
must be set here.
Device address 1 — 255 Device address for the
Modbus protocol.
