2 Instrument description
2.1 Displays and controls
1. CompactFlash
®
is a registered trademark of the SanDisk Corporation.
2. Not from the configuration level if a parameter has already been modified there.
Power LED (green)
is on continuously as soon as power is applied.
Flashes when screen saving is active.
Pressing any key will de-activate screen saving.
Status LED (red)
is on continuously while an alarm is present
Cover
for the CompactFlash
®
slot
1
and the setup plug connection
Enter
- select menu item
- enter selection
Menu
back to the start menu
2
Exit
- previous window
- cancel current action
Softkeys
screen-dependent functions, represented by text or symbols
Color display
320 x 240 pixel, 27 colors
