3 Operation and visualization
Text field (4) Text field (4) is filled automatically by the recorder and cannot be altered.
Example: Parameter setting for line 8
Example: Parameter setting for line 9
Example: Parameter setting for line 10
Parameter for line 8
Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 8 ➔ Contents right column
Batch start
Parameter for line 9
Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 9 ➔ Contents right column
Batch end
Parameter for line 10
Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 10 ➔ Contents right column
Batch duration
