4 Configuration parameters
88
Control signal
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Control signal
LogInp. 1 — 7,
Alarm Gr.1 — 6,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF plugged in
Stolen CF
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card
If the status of the external
report or the batch report is
not set to OFF, the report is
started and completed by
activating the control
signal
Text (left column)
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Batches
➔ Line 1 — 10
➔ Text
left column
any text The texts in the left column
of a batch report are
entered here.
v Chapter 3.2.8 “Batch
reports”
v Chapter 3.8 “Text entry”
Contents right
column
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Batches
➔ Line 1 — 10
➔ Contents
right
column
No entry,
Fixed text,
Text list,
Bin.-linked text,
from interface,
Batch No.,
Batch start,
Batch end,
Batch duration
Determines how the text in
the right-hand column of a
batch report is formed.
v Chapter 3.2.8 “Batch
reports”
Binary-linking
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Batches
➔ Line 1 — 10
➔ Binary
linking
Logic inp1-2,
Logic inp1-3,
Logic inp1-4,
Logic inp1-5,
Logic inp1-6,
Through binary linking, up
to 64 different texts can be
incorporated into the batch
report by means of the
logic inputs (depending on
the setting).
v Chapter 3.2.8 “Batch
reports”
from text No.
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Batches
➔ Line 1 — 10
➔ f rom text No.
1 — 146 First text in the internal text
list. Only used for “right-
hand column = text list”
and “right-hand column =
binary linking”.
v Chapter 3.2.8 “Batch
reports”
to text No.
(Ext.report/
Batches)
Configuration
➔ Report/Batches
➔ Ext. report/Batches
➔ Batches
➔ Line 1 — 10
➔ to text No.
1—2 — 146 Last text in the internal text
list. Only used for “right-
hand column = text list”.
v Chapter 3.2.8 “Batch
reports”
