Jungheinrich KMS 100 User Manual

1298.GB
B 6
Basic dimensions
4.2 Height with hoist frame retracted h
1
(mm) 3830
4.3 Free lift h
2
(mm) -
4.4 Length of lift h
3
(mm) 5500
4.5 Height with hoist frame extended h
4
(mm) 7820
4.7 Height above vehicle shed (cabin) h
6
(mm) 2300
4.8 Seating/standing height h
7
(mm) 290
4.11 Auxiliary lifter h
9
(mm) 840
4.12 Total length of lift h
10
(mm) 6340
4.14 Commissioning height h
15
(mm) 7390
4.15 Lowered height h
13
(mm) 70
4.19 Total length without load l
1
(mm) 2870
4.20 Length incl. fork back l
2
(mm) 2070
Distance swivel reach fork pivot L
3
(mm) -
4.21 Total width b
1
/b
2
(mm) 1010 / 1000
4.22 Fork tine dimensions s/e/l (mm) 40 x 100 x 800
4.23 Fork carrier DIN 15173, class/shape A, B - -
4.24 Fork carrier width b
3
(mm) 830
4.25 Overall distance of fork b
5
(mm) 830
4.27 Width of guide rollers b
6
(mm) 1200
4.29 Reach, sidewards b
7
(mm) -
4.30 Reach, sidewards from the center of the vehicle b
8
(mm) -
4.31 Road clearance with load below hoist frame m
1
(mm) 75
4.32 Ground clearance in wheel base center m
2
(mm) 67
4.33
Working aisle width for pallet
1000 x 1200
sideways
A
st
(mm) 1400
4.34
Working aisle width for pallet
800
x 1200 lengthways
A
st
(mm) 1200
4.35 Turning circle W
a
(mm) 1723
4.36 Pallet width b
12
(mm) 1200
4.37 Pallet length l
6
(mm) 800
4.38 Distance swivel fork pivot l
8
(mm) -
4.39 Cabin depth entrance (mm) 530
4.41 Clear cabin height inside h
11
(mm) 2000
4.42 Driver's seat carrier width outside b
9
(mm) 1200
4.43 Width swivel push frame b
14
(mm) -
4.44 Width jib l
10
(mm) -
1298.GB
B 6
Basic dimensions
4.2 Height with hoist frame retracted h
1
(mm) 3830
4.3 Free lift h
2
(mm) -
4.4 Length of lift h
3
(mm) 5500
4.5 Height with hoist frame extended h
4
(mm) 7820
4.7 Height above vehicle shed (cabin) h
6
(mm) 2300
4.8 Seating/standing height h
7
(mm) 290
4.11 Auxiliary lifter h
9
(mm) 840
4.12 Total length of lift h
10
(mm) 6340
4.14 Commissioning height h
15
(mm) 7390
4.15 Lowered height h
13
(mm) 70
4.19 Total length without load l
1
(mm) 2870
4.20 Length incl. fork back l
2
(mm) 2070
Distance swivel reach fork pivot L
3
(mm) -
4.21 Total width b
1
/b
2
(mm) 1010 / 1000
4.22 Fork tine dimensions s/e/l (mm) 40 x 100 x 800
4.23 Fork carrier DIN 15173, class/shape A, B - -
4.24 Fork carrier width b
3
(mm) 830
4.25 Overall distance of fork b
5
(mm) 830
4.27 Width of guide rollers b
6
(mm) 1200
4.29 Reach, sidewards b
7
(mm) -
4.30 Reach, sidewards from the center of the vehicle b
8
(mm) -
4.31 Road clearance with load below hoist frame m
1
(mm) 75
4.32 Ground clearance in wheel base center m
2
(mm) 67
4.33
Working aisle width for pallet
1000 x 1200
sideways
A
st
(mm) 1400
4.34
Working aisle width for pallet
800
x 1200 lengthways
A
st
(mm) 1200
4.35 Turning circle W
a
(mm) 1723
4.36 Pallet width b
12
(mm) 1200
4.37 Pallet length l
6
(mm) 800
4.38 Distance swivel fork pivot l
8
(mm) -
4.39 Cabin depth entrance (mm) 530
4.41 Clear cabin height inside h
11
(mm) 2000
4.42 Driver's seat carrier width outside b
9
(mm) 1200
4.43 Width swivel push frame b
14
(mm) -
4.44 Width jib l
10
(mm) -
