Jungheinrich KMS 100 - Symbols Indicating the Trucks Operating Status

1298.GB
E 6
3.3 Symbols indicating the truck’s operating status
After switching on the truck’s operating status is indicated in the display.
Barriers open
Foot-operated switch not activated
If the following symbols are displayed, a reference run must be carried out according
to the indication, i.e. the main lift must be lifted by approx. 30 cm and lowered again.
Then the control gives a release to carry out all movements of the truck with full
speed.
Reference run: Lift main lifter
Reference run: Lower main lifter
