4.1 Truck identification label
In the event of queries relating to the truck or spare part orders, please state the serial
no. (19) of the truck.
4.2 Load capacity
The label (12) shows a table with the capacity Q of the truck in relation to the load
center distance (D in mm) and the lifting height (H in mm).
Pos. Description Pos. Description
18 Model 24 Load centre distance in mm
19 Serial no. 25 Min./max. battery weight in kg
20 Order no. 26 Net weight without battery in kg
21 Capacity in kg 27 Year of manufacture
22 Battery: voltage V
Ampere hours Ah
28 Type no.
23 Maker 29 Maker’s logotype
