05.10 EN
20
1)
for vertical mast.
2)
The values shown represent the maximum gradeability to overcome short
differences in height and surface unevenness (surface edges). The truck must not
operate on inclines of more than 15%.
TFG 316s-320s
Description TFG 316s TFG 320s
Q
Capacity
(where C = 500 mm)
1)
1600 2000 kg
C Load centre 500 500 mm
Travel speed * w. /
w.o. load
19.5/19.5 19.5/19.5 km/h
Lift speed, w. / w.o. load 0.60/0.62 0.60/0.62 m/s
Lower speed, w. / w. o.
load
0.54/0.57 0.54/0.57 m/s
Gradeability
2)
w /
w.o. load
27 26 %
Acceleration time * w
/ w.o. load to 15 m
5.0/4.6 5.1/4.7 s
Available working
pressure for attachments
160 160 bar
Oil flow for attachments 30 30 l / min
