05.10 EN
100
4.16 Assembly and hydraulic ports of additional attachments
WARNING!
Incorrectly connected attachments can cause accidents.
Attachments with incorrectly connected hydraulic attachments can result in
accidents.
XAttachments must only be assembled and commissioned by trained, specialist
personnel.
XNote the attachment manufacturer’s operating instructions.
XBefore commissioning, check the fasteners are positioned correctly and securely
and make sure they are complete.
XBefore commissioning, make sure the attachment is working correctly.
Hydraulic ports
Requirements
– Non-pressurised hydraulic ports.
– The exchange ports on the truck are marked ZH2 and ZH3.
– Attachment directions of movement defined to match the controls’ direction of
movement.
Procedure
• Non-pressurised hydraulic hoses
• Switch off the truck and wait a few minutes.
• Attach the plug connector and engage it in position.
• Mark the controls with symbols that indicate their function.
The attachment is now hydraulically connected.
WARNING!
Hydraulic ports for clamping attachments
XClamping attachments may only be added to trucks which have a button to enable
additional hydraulic functions.
XOn trucks with auxiliary hydraulics ZH2 the clamping function should only be
attached to the coupling pair marked ZH2.
XOn trucks with auxiliary hydraulics ZH3 the clamping function should only be
attached to the coupling pair marked ZH3.
