21
05.10 EN
3.2 Dimensions
DFG/TFG 316s-320s Hydrostatic
Manufacturer's name / type
Jungheinrich
DFG/TFG 316s-
320s
DFG/TFG 316s-
320s
a/2 Safety distance 100 100 mm
h
1
Mast height retracted* 2185 2185 mm
h
2
Free lift* 150 150 mm
h
3
Lift* 3300 3300 mm
h
4
Mast height extended* 3920 3920 mm
h
6
Overhead guard height* 2145 2145 mm
h
7
Seat height 1048 1048 mm
h
10
Coupling height 380 380 mm
a Mast tilt, fwd.* 7 7 °
ß Mast tilt, back* 7 7 °
L1 Overall length, including forks* 3453 3473 mm
L2 Overall length, including fork
shank*
2303 2323 mm
b1 Overall width* 1100 1100 mm
s/e/l Fork dimensions* 40x100x1150 40x100x1150 mm
m1 Ground clearance with load
below mast*
120 120 mm
m2 Ground clearance centre
wheelbase*
120 120 mm
Fork carriage DIN 15173, class
A/B
IIA IIA
b3 Fork carriage width 980 980
Ast Working aisle width for pallets
800 x 1200 longit.
3835 3853 mm
Ast Working aisle width for pallets
1000 x 1200 traverse
3635 3653 mm
Wa Turning radius 2037 2055 mm
b13 Smallest turning radius 545 545 mm
x Load distance* 398 398 mm
c Load centre of gravity 500 500 mm
y Wheelbase 1550 1550 mm
