Jungheinrich TFG 320s User Manual

05.10 EN
68
3.4.3 Adjusting the arm rest
Horizontal adjustment:
Procedure
• Undo the clamping screw (139) a few
turns.
• The armrest can now be moved forward
or back.
When you have reached the required
setting, tighten the clamping screw (139)
again; this will lock the armrest in place.
Vertical adjustment:
Procedure
• Depress the locking button (140) and hold it in place.
• The armrest can now be adjusted upwards or down.
When you have reached the required setting, release the locking button (140); this
will lock the armrest in place.
139
140
