Table 15: Optical Interface Support for Gigabit Ethernet SFP Transceivers (continued)

ValueSpecificationEthernet Standard

EX-SFP-1GE-LXModel Number1000BASE-LX

1000 MbpsRate

LCConnector Type

DualFiber Count

1310 nmTransmitter Wavelength

–9.5 dBmMinimum Launch Power

–3 dBmMaximum Launch Power

–25 dBmMinimum Receiver Sensitivity

–3 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

10 km (6.2 miles)Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 11.3 or laterSoftware Required
