2
11
Preparation
Item Description
1 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate blue and then blink red and blue confirming that a timer
recording programme has started in the standby mode.
3 Disc Slot
Insert a disc with the label side facing towards the rear of the TV. (12 cm discs only.
Don't insert 8 cm discs.)
4
Press to eject disc. (DVD mode)
5
Press to start playback or pause. (DVD mode)
6 VOL + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
7 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
8 MENU Displays the OSD (on screen display) menu.
9 INPUT
Press to select among different input signal sources:
Digital TV / Analogue TV / HDMI 1 / HDMI 2 / HDMI 3 / AV / SCART / YPbPr / DVD / PC /
USB.
Use the
buttons on the remote control to select the input, and then press the OK
button to confirm.
10
Switches the TV on from standby mode.
Switches the TV back to standby mode.
Front / Right Side View and Rear Controls
6
7
8
9
10
INPUT
3
1
2
4
5
To Next Page
