4K HDBaseT™ 8x8 Matrix Switcher
MX-HDBASE8X8-4K 5
KanexPro.com
correspond to 8 output sources separately, communicate
with the RS232 port on corresponding HDBaseT receiver,
and cannot be switched separately. When controlled by
HDBaseT receiver, the communication protocol must be
the same with the matrix switcher’s.
f. AUDIO: stereo audio output ports, 8 in total
g. HDMI: Local HDMI output ports for HDMI Inputs 1~4,
synchronously switched with HDBaseT Output 1~4
h. HDBaseT: output extension ports, works with HDBaseT
receivers to extend signals and power far-end HDBaseT
receiver on a single CAT5e/6 cable.
Serial port for unit control, 9-pin female connector, connects
with control device such as a PC.
Input port for IR control signal; connect with IR receiver (with
carrier), delivers the received IR signal to all the 8 far-end
receivers.
TCP/IP port for unit control
Connect with extended IR receiver; use the IR remote to
control the matrix switcher.
Press the button to turn on/off the matrix. The indicator turns
red when power on.
Connect to an AC 100V~240V power adapter via the included
power cord
Connect to grounding; make sure the unit is grounded well.
Note: Pictures shown in this manual are for reference only; different model and
specifications are subject to real product.
3. System Connection
3.1 System Applications
As its good performance in control and transmission, the matrix switcher can be widely
used in computer realm, monitoring, large screen displaying, conference system,
television education and bank securities institutions etc.
3.2 Usage Precautions
1) System should be installed in a clean environment and has a prop temperature and
humidity.
2) All of the power switches, plugs, sockets and power cords should be insulated and
safe.
3) All devices should be connected before power on.
