4K HDBaseT™ 8x8 Matrix Switcher
MX-HDBASE8X8-4K 1
KanexPro.com
1. Introduction
1.1 The MX-HDBASE8X8-4K
The KanexPro MX-HDBASE8X8-4K matrix switcher is a professional 8 HDMI input to 8
HDBaseT output switch with 4 HDMI mirrored outputs designed for routing 4K/UHD
applications. For proficient audio capabilities it includes 8 auxiliary audio inputs for
stereo and 8 stereo outputs for HDMI audio de-embedding and 8 IR inputs. The HDMI
inputs from the matrix can be controlled via front panel buttons, bi-directional IR &
RS232, or in GUI mode using Ethernet. The selected source is delivered to HDMI
Output 1~4(for HDMI input 1~4) & HDBaseT outputs 1~8 (easy extension to 70m at
1080p and 40m at 4Kx2K on a single CAT5e/6 connection with optional PoE based
HDBaseT receivers) simultaneously. The unit provides built-in EDID and HDCP
management.
1.2 Features
! Ultra-fast 8x8 switching with instant display
! Distribute eight HDBaseT outputs up to 70m at 1080p & 40m at 4Kx2K on a single
CAT5e/6 cable.
! Supports power over Ethernet (PoE) to all eight receivers
! Four HDMI mirrored outputs for local monitor support
! Deep color support up to 16 bit
! RGB/YCbCr 4:4:4, YCbCr: 4:2:2, 4K/30Hz
! Illuminated buttons w/ Front panel LCD
! Dedicated audio zones for digital and stereo audio
! Audio De-embedding
! Advanced EDID & HDCP management
! Bi-directional IR & RS-232 control
! Built-in GUI using Ethernet connectivity
! Controllable via front panel, RS232, IR & IP
! IR remote control included
! Easy firmware upgrade thru Micro-USB port
! Locking HDMI connectors
! 2 RU rack-mountable steel enclosure
