4K HDBaseT™ 8x8 Matrix Switcher
MX-HDBASE8X8-4K 18
KanexPro.com
4.3.4 RS232 Communication Commands
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Function
Feedback Example
System Commands
/*Type;
Inquire the models information.
MX-HDBASE8X8-4K
/%Lock;
Lock the front panel buttons on the Matrix.
System Locked!
/%Unlock;
Unlock the front panel buttons on the
Matrix.
System Unlock!
/^Version;
Inquire the version of firmware
VX.X.X
/:MessageOff;
Turn off the feedback command from the
com port. It will only show simple words
like “SWITCH OK!”.
/:MessageOff;
/:MessageOn;
Turn on the feedback command from the
com port.
/:MessageOn;
Demo.
Switch to the “demo” mode, convert input
and output in turn like1B1, 1B2, …8B7,
8B8, 1B1… and so on.
The switching interval is 2 seconds.
Demo Mode
AV: 1-> 1
AV: 1-> 2
AV: 1-> 3
AV: 1-> 4
AV: 1-> 5
AV: 1-> 6
AV: 1->7
AV: 1->8
AV: 2-> 1
…
Undo.
To cancel the previous operation.
Undo Ok!
Out 1 2 3 4
In 1 1 1 1
Out 5 6 7 8
In 1 1 1 1
Operation Commands
[x]All.
Transfer signals from the input channel [x]
to all output channels
X To All.(X=1~8)
All#.
Transfer all input signals to the
corresponding output channels
respectively like 1->1, 2->2…
All Through.
All$.
Switch off all the output channels.
All Closed.
[x]#.
Transfer signals from the input channel [x]
to the output channel [x].
X Through.(X=1~8)
